1000mm Belt Width Overband Magnetic Separator 1000*1250mm Dimension

Basic Information
Place of Origin: Hunan, China (Mainland)
Brand Name: SHENGANG
Certification: based on ISO quality control system
Model Number: RCDB-10
Minimum Order Quantity: 1 Piece/Pieces
Price: Negotiable
Packaging Details: standard export package(China Scrap Circular Magnetic Separator Manufacturer)
Supply Ability: 70 Piece/Pieces per Month China Scrap Circular Magnetic Separator Manufacturer
Condition: New Type: Magnetic Separator, Electromagnet Type
Voltage: Based On Customer Needs, DC-220 Power(W): 5.65KW
Dimension(L*W*H): 1000*1250mm Weight: 1460KG
Product Name: China Scrap Circular Magnetic Separator Manufacuturer Color: Red
Duty Cycle: TD-100% Belt Width: 1000mm
Standard Erection Height: 300mm Application: Magnetic Separator To Remove Magnetic Tramp Iron
After-sales Service Provided: Engineers Available To Service Machinery Overseas
High Light:

magnetic separator conveyor belts

,

magnetic roll separator

China Scrap Circular Magnetic Separator Manufacturer



Application:



•Remove magnetic tramp metals (0.1 - 25 kg ) from thicker materials bed and coal, for improving or purifying hard coke, ores, limestone, spall, corns and wooden shavings under bigger granularity.
•Clean by hand
•With three sets of adjustable hooks to adjust erection and installation height conveniently



Benifits:



Improving and purifying non-magnetic materials; Recycling iron

Technical Data and Overall Dimension:



Model T(mm) Erection height Belt width (mm)

Rated Voltage

(V)

Cold Power

(kw)

Mass

(kg)

Overall dimension(mm)
A
(outer dimension)
H
(Hanging height)
RCDB-3(MC03-30L) 100 300 DC-48 0.18 85 300 600
RCDB-4(MC03-40L) 120 400 DC-60 0.7 126 400 700
RCDB-5(MC03-50L) 150 500 DC-110 1.13 236 500 750
RCDB-7(MC03-70L) 200 650 2.2 580 700 890
RCDB-8(MC03-80L) 250 800 3.08 1150 900 1160
RCDB-10(MC03-100L) 300 1000 DC-220 5.65 1460 1100 1250
RCDB-12(MC03-120L) 350 1200 7.92 2241 1300 1280
RCDB-14(MC03-140L) 400 1400 DC-290 9.7 3480 1500 1390
RCDB-16(MC03-160L) 450 1600 10.33 4506 1650 1550
RCDB-18(MC03-180L) 500 1800 11.1 4882 1800 1640

 Overall Dimension Drawing:

 1000mm Belt Width Overband Magnetic Separator 1000*1250mm Dimension 0

Magnetic Separator
Complete equipment and Application:



1000mm Belt Width Overband Magnetic Separator 1000*1250mm Dimension 1

FAQ

In order to provide you with the best quotation at the shortest time, we need you kindly inform below points to do model selection :

1.what kind of material need to process separation?



2.does it work with belt? if yes, how about the belt width? belt speed?



3.how about the handling capacity you require? and the separation material size?



4.do you need self-discharging type or manual discharge type?



5.rectangular shape or round shape? permanent magnet type or electromagnet type?



Company Information:


We are a professionl lifting electromagnet equipment manufacturer and exporter. Very sincerely looking for long-term win-win business here!



Major exports include lifting electromagnet, magnetic lifter, electromagnetic separator, cable reel, control cabinet and magnetic stirr, etc. with more than 15 years export experience.



Our factory also pass the SGS audit per year with certification issued.



We warmly welcome you to enquiry or visit us, and also appreciate any of your comments!



We also have our own brand as "SHENGANG"

1000mm Belt Width Overband Magnetic Separator 1000*1250mm Dimension 2



Other magnetic Separators:
The separator is used to separate or eliminate magnetic iron materials from non-magneic material in metallurgical,mining,power,seaport,ceramic industry,etc.



1000mm Belt Width Overband Magnetic Separator 1000*1250mm Dimension 3

Packaging & Shipping:


 (fixed iron frame with five-plywoodboard packing to keep Scrap Circular Magnetic Separator Manufacuturer with a safety and long-distance transportation and no need fumigation when clear custom )



Quick Response:


We highly appreciate your any enquiry by email, fax or instant message.

We will reply your email or fax within 24 hours.

Please fell free to call us at any time if there is any questions.



Convenient Transportation:



All available shipping ways could be applied, by courier, air or sea.

Appointed shipping company or our own forwarders all could be used in shipment.

Full-way tracking the cargos for you till the goods arrive.
