| Place of Origin: | Hunan, China (Mainland) |
|---|---|
| Brand Name: | SHENGANG |
| Certification: | SGS |
| Model Number: | RCDF-8 |
| Minimum Order Quantity: | 1 Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | standard export package(Cross Belt Magnetic Separator Oil Cooling RCDF Series) |
| Supply Ability: | 70 Set/Sets per Month cross belt magnetic separator oil cooling rcdf series |
| Condition: | New | Type: | Magnetic Separator, Electromagnet Type |
|---|---|---|---|
| Production Capacity: | High | Voltage: | 220V, DC-220 |
| Power(W): | 2.2kw | Dimension(L*W*H): | 2650*810*1035MM |
| Weight: | 2700kg, 2200kg | Product Name: | Cross Belt Magnetic Separator Oil Cooling RCDF Series |
| Color: | Red | Power: | 2.2kw |
| Duty Cycle: | TD-100% | Belt Width: | 800mm |
| Standard Erection Height: | 250mm | Application: | Magnetic Separator To Remove Magnetic Tramp Iron |
| Warranty: | 12 Months | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Port: | Shanghai/Shenzhen/Guangzhou | ||
| High Light: | small strong magnets,magnetic lifting tool |
||
Cross Belt Magnetic Separator Oil Cooling RCDF Series
-- Hanging Magnetic Separator for Coal Plant RCDF Series
--Oil-Cooling Type
Brief Introduction:
Series RCDF dry selfcleaning electromagnetic iron separator is a kind of magnetic equipment which
is using in the iron removal from the nonmagnetic material . It usually be installed in the front or
center of the belt conveyor. The strong magnetic will absorb the pieces of iron which mixed with
the materials and dished out by the irondischarging belt, achieving thepurpose of selfcleaning,and
it can prevent the discharging belt longitudinal crack,and ensure that the breaker and grinder work normally .
Application:
This series iron separator is widely used in electricity,mine,metallurgy,building material,coal dressing,
chemical industry,etc.
Benifits:
Improving and purifying non-magnetic materials; Recycling iron
Technical Data and Overall Dimension:
Model | Belt width | Suspension height | Belt speed | depth | Excitation power | weight | Dimension mm | |||||
A | B | C | D | E | F | |||||||
RCDE-5 | 500 | 150 | 2.5 | 100 | 1.2 | 450 | 680 | 750 | 450 | 450 | 435 | 500 |
RCDF-5 | 1100 | 1900 | 900 | 800 | 650 | 1050 |
| |||||
RCDE-6 | 600 | 175 | 125 | 1.8 | 650 | 780 | 800 | 550 | 550 | 480 | 600 | |
RCDF-6 | 1500 | 2100 | 1000 | 850 | 700 | 1170 |
| |||||
RCDE-6.5 | 650 | 200 | 150 | 2.0 | 750 | 800 | 820 | 600 | 600 | 485 | 650 | |
RCDF-6.5 | 1800 | 2200 | 1050 | 900 | 750 | 1270 |
| |||||
RCDE-8 | 800 | 250 | 200 | 2.2 | 1150 | 940 | 900 | 750 | 775 | 580 | 835 | |
RCDF-8 | 2200 | 2650 | 1250 | 970 | 810 | 1500 |
| |||||
RCDE-10 | 1000 | 300 | 250 | 4.5 | 1500 | 1200 | 980 | 950 | 1000 | 630 | 1080 | |
RCDF-10 | 3550 | 3000 | 1500 | 1080 | 810 | 1580 |
| |||||
RCDE-12 | 1200 | 350 | 300 | 6 | 2550 | 1400 | 1080 | 1150 | 1050 | 720 | 1150 | |
RCDF-12 | 4650 | 3250 | 1700 | 1200 | 940 | 1780 |
| |||||
Overall Dimension Drawing:
Physical Product Photot:
In order to provide you with the best quotation at the shortest time, we need you kindly inform below points to do model selection :
1.what kind of material need to process separation?
2.does it work with belt? if yes, how about the belt width? belt speed?
3.how about the handling capacity you require? and the separation material size?
4.do you need self-discharging type or manual discharge type?
5.rectangular shape or round shape? permanent magnet type or electromagnet type?
