| Place of Origin: | Hunan, China (Mainland) |
|---|---|
| Brand Name: | SHENGANG |
| Certification: | ISO9001 |
| Model Number: | CTZ-50/50 |
| Minimum Order Quantity: | 1 Set/Sets |
| Price: | Negotiable |
| Packaging Details: | standard export package(permanent magnetic roller) |
| Supply Ability: | 50 Set/Sets per Month |
| Condition: | New | Type: | Magnetic Separator |
|---|---|---|---|
| Production Capacity: | 30t/h | Dimension(L*W*H): | 500*500*600mm |
| Weight: | 360kg, 360kg | Product Name: | Permanent Magnetic Roller |
| Magnetic Intensity: | 3000GS | Color: | Per Customer' Requirement |
| Rotary Speed: | 20-30(r/min) | Electromagnet Type: | Permanent Magnet |
| Length Of Drum: | 600mm | Roller Diameter: | 500mm |
| Adaptive Belt Width: | 500mm | Application: | Widely Used In Metallurgy, Ceramics,etc.. |
| Warranty: | 12 Months | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Port: | Shanghai/Shenzhen/Guangzhou | ||
| High Light: | magnetic separation equipment,magnetic coolant separator |
||
Permanent Magnetic Roller
for Mineral Separation
Brief Introduction:
Series CTZ permanent magnetic roller (magnetic pulley, magnetic drum) is usually used for the purification treatment of powdery, granular, small block materials and the recycling of iron. It includes two kinds of magnetic system structure of semi-magnetic and full-magnetic. Besides, the machine can prevent the crushing machines, grinding machines and pressing machines from being damaged and abraded by tramp iron.
Feature:
Application:
Widely used in metallurgy, ceramics, abrasives, carborundum, non-metallic minerals, refractory materials, mining, food, chemical, glass, building materials and other industries.
Technical Data:
|
Model No. |
Diameter of drum |
Adaptive belt width |
Length of drum (mm) |
Magnetic intensity (mT) |
Rotary speed |
Iron removing capacity (t/h) |
|
|
Powdery materials |
Bulk materials |
||||||
|
CTZ-50/50 |
500 |
500 |
600 |
300 |
20~30 |
3.5 |
30 |
Note: 1 mT = 10 gauss
Overall Dimension Drawing:
Physical Product Photo:
Standard Export Package:
(fixed iron frame with five-plywoodboard packing to keep safety and long-distance transportation)
